CE/PFCC202/HGW2082.5 Canvas Phenolic Sheets

CE/PFCC202/HGW2082.5 Sheets are high-quality phenolic laminates designed for superior electrical insulation, heat resistance, and mechanical strength. They are ideal for industrial applications requiring durable, reliable, and stable performance under extreme conditions.
Availability:
Quantity:
telegram sharing button
snapchat sharing button
kakao sharing button
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Product Details

CE/PFCC202/HGW2082.5 Canvas Phenolic Sheets
These sheets are produced by impregnating paper or fabric with phenolic resin, which is then compressed and cured to form a rigid, durable laminate. Known for their excellent electrical insulation properties, these sheets provide superior dielectric strength, making them suitable for high-voltage applications.

The sheets also exhibit high resistance to heat and fire, withstanding temperatures up to 120°C (Class E) while maintaining their mechanical integrity. Their low moisture absorption rate ensures that they perform consistently even in humid environments, making them ideal for applications where stability is critical. These sheets also offer excellent arc resistance, enhancing their safety in electrical applications.

These laminates are designed for easy machining and are used in the production of precision components that require both electrical and mechanical performance. Their durability and resistance to wear make them highly reliable in industrial machinery, electrical components, and more.

Product Parameters

Standard
IEC60893-3-4
NEMALI-1
DIN 7735
MIL-I-24768/14 FBG
Density
1.4 g/cm³
Dielectric Constant
≤ 5.5 Hz
Tensile Strength
≥ 60 MPa
Thermal Class
Class E (120°C)
Specific Gravity
1.37

Product Advantages

Product Advantages Icon

Excellent Electrical Insulation

With a dielectric strength of ≥ 35 kV/mm, these sheets provide reliable electrical insulation, making them ideal for high-voltage applications in transformers and switchgear.

Product Advantages Icon 1

High Heat Resistance

These sheets withstand temperatures up to 120°C (Class E), ensuring long-lasting performance in high-temperature environments without compromising their mechanical properties.

Product Advantages Icon 2

Durability and Resistance to Moisture

These laminates are resistant to moisture, maintaining stability and performance in humid conditions. Their ability to endure physical stress makes them ideal for demanding industrial and electrical applications.


Product Applications

FAQ

  • What is the minimum order quantity?
    Created with Sketch.
    形状 Created with Sketch.
    The minimum order quantity depends on the specific product you are interested in. For detailed information, please contact us directly via email or WhatsApp.
  • What is the price of this product?
    Created with Sketch.
    形状 Created with Sketch.
    The price of our products varies depending on the quantity, size, and specifications. For an accurate quote, please reach out to us via email or WhatsApp, and we'll provide you with the best options tailored to your needs.
  • What is the average delivery time?
    Created with Sketch.
    形状 Created with Sketch.
    Delivery times vary based on the quantity and specifications of the order. Typically, delivery can take anywhere from 3 to 30 days. For more precise information, please contact us directly via email or WhatsApp.
