When you operate a vessel in saltwater, high humidity, or extreme temperatures, ordinary materials often fail. Steel corrodes. Standard plastics warp or burn. That is why marine engineers increasingly specify high-performance thermoset composites.
epoxy resins, glass fiber, phenolic resins, and polyester fiber – offers a unique combination of wear resistance, electrical insulation, heat tolerance, and chemical resilience. In the shipbuilding world, these properties translate directly into longer service life, lower maintenance, and improved safety.
Below we walk through the most common grades (G10, FR-4, G11, EPGC201, EPGC203, EPGM203), where they go on a ship, and how to choose the right one.
Not every composite handles seawater and engine heat equally. Here is a practical breakdown.
G10 / EPGC201
Glass fabric + epoxy
Maximum continuous temperature ~130°C
Very low water absorption (0.05–0.3%)
Excellent mechanical strength and dimensional stability
Not flame-retardant (UL94 HB)
FR-4 / EPGC202
Flame-retardant epoxy with glass cloth
UL94 V-0 rating – critical for fire safety in enclosed ship compartments
Slightly higher temperature rating (~130°C)
Outstanding electrical insulation
G11 / EPGC203
Modified epoxy for high heat
Continuous use up to ~150°C
Retains mechanical and electrical properties even when hot
Ideal near engines, exhausts, or steam lines
EPGM203
Epoxy with glass mat reinforcement (not woven cloth)
Isotropic – same strength in all directions
Can reach H-class temperature rating (180°C)
Very low water absorption (0.06% after 24 hours)
Excellent machinability for complex shapes
All four grades resist seawater, salt spray, and most chemicals found in marine environments. No additional coating is required for corrosion protection.
Bilge keel washers, mast seats, deck equipment foundations
G10 or EPGC201 work well here because of their high load capacity and vibration damping.
Propeller shaft and rudder bearings
Many modern vessels use epoxy glass laminates for water-lubricated bearings. They have low friction and do not swell. IACS unified requirement UR M85 already covers type approval for such bearings.
Engine mounts and stiffeners
For engine rooms, pick G11 or EPGC203. Those grades withstand the heat radiated from main engines and generators without softening.
Ships are packed with switchboards, motors, and cables. Moisture and salt can easily cause short circuits.
High-voltage switchboard panels – FR-4 is the standard because it self-extinguishes.
Bus bar supports and transformer insulation – G11/EPGC203 keeps its dielectric strength even when ambient temperatures rise.
Cable transit blocks – Some modern GRP sealing systems (e.g., Roxtec) are laminated or bonded directly into composite bulkheads, avoiding drilled holes that could crack the material.
Flanges for pumps, valves, and piping need insulating gaskets that do not leak or corrode.
EPGM203 is the top choice for complex gasket shapes. Because it is isotropic, you can machine it in any direction without worrying about weak spots. Its low water absorption ensures a tight seal even after years submerged.
LNG / LPG carrier tank support blocks
Special epoxy laminates (often similar to EPGM203 or dedicated laminate sheet) insulate the steel hull from extreme cold. They bear huge point loads while preventing brittle fracture of the tank structure.
Thermoset composites cannot be melted and re-shaped. You will machine them using CNC equipment – milling, turning, drilling, grinding.
For large flat panels – G10, FR-4, and G11 are anisotropic (stronger along the fabric direction). Design your part orientation accordingly.
For small, complex parts – EPGM203 is easier to machine because it has no directional fibers. You get consistent hole quality and edge finish.
A practical tip: When attaching fittings to composite panels, avoid through-bolting whenever possible. Use bonded inserts or GRP-compatible sealant systems. Drilling can create stress risers and allow moisture wicking into the laminate.
To sell composite materials for shipboard components, you need the right approvals. Here is what matters.
Base material standards
NEMA LI 1-1998 (US)
IEC 60893 series (international)
MIL-I-24768 (US military)
GB/T 1303.1-1998 (China)
Ship classification societies – each has its own flavor:
| Society | Key focus |
| CCS (China) | Good local support, lower cost for Chinese manufacturers |
| DNV (Norway) | Very high market share in Europe; strict on environmental and digital documentation |
| ABS (USA) | Widely used for tankers and offshore units; flexible standards |
| LR (UK) | Very high technical scrutiny |
| BV (France) | Publishes specific rules for bonded composite assemblies (NR 546) |
Typical approval process
Submit technical data and test plan.
Perform type tests at a class-approved lab – mechanical, thermal, electrical, flammability (smoke density, toxicity), and salt spray aging.
Factory audit (you need ISO 9001).
Certificate issuance and annual surveillance.
Without class approval, you cannot supply critical parts like shaft bearings or switchboard insulators. For non-critical components (deck covers, simple brackets), a material datasheet plus mill certificate may be enough – but always check with the shipyard.
Ask your customer these three questions:
Is fire resistance required?
Yes → FR-4/EPGC202.
No → G10 or G11 depending on temperature.
Will the part be near an engine or exhaust?
Yes → G11/EPGC203 (up to 150°C) or EPGM203 (up to 180°C).
No → G10 is fine.
Is the part shape very complex, with undercuts or thin walls?
Yes → EPGM203 (isotropic and easy to machine).
No → any woven-cloth grade can work.
Q: How do I prove long-term performance in seawater?
A: The low water absorption numbers (e.g., 0.06% for EPGM203) are a start. But class societies will also require accelerated aging data – for example, mechanical strength retention after 1,000 hours of salt spray or 90 days of immersion. Provide a full type test report from an accredited lab.
Q: Can I use FR-4 for a structural engine mount?
A: Yes, if the temperature stays below ~130°C and you do not need the higher heat tolerance of G11. However, note that FR-4 is slightly less tough than G10. For heavy dynamic loads, G10 or G11 is safer.
Q: Do these composites absorb water over many years?
A: All epoxy-based glass laminates have very low equilibrium water absorption – typically under 0.5% even after long immersion. That is far better than nylon or phenolic materials. The mechanical properties may drop a few percent, but they remain stable. No coating is needed for corrosion protection.
For a composite manufacturer, the marine sector offers steady demand – from small workboats to LNG carriers. Fenhar G10, FR-4, G11, EPGC201, EPGC203, and EPGM203 grades already cover most of what a ship needs: strength, insulation, fire resistance, heat tolerance, and seawater durability.
Focus on getting class society certification for your most common thicknesses (e.g., 3mm, 6mm, 12mm). Then work with local shipyards to replace traditional steel or phenolic parts. The weight savings and maintenance-free operation will sell themselves.
